AFL-W10A-N270 User Manual
Page 85
5.2.4 Audio DMIC-in Connector (DMIC1)
5.2.5 Battery Connector (BT1)
5.2.6 CompactFlash® Type II Slot (CF1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND1 26 CD1
2 DATA 3 27 DATA 11
3 DATA 4 28 DATA 12
4 DATA 5 29 DATA 13
5 DATA 6 30 DATA 14
6 DATA 7 31 DATA 15
7 CE 32 CE2
8 A10 33 VS1
9 OE 34 IOR
10 A9 35 IOW
11 A8 36 WE
12 A7 37 IRQ
13 VCC1 38 VCC2
14 A6 39 CSEL
PIN NO. DESCRIPTION
1 DMIC_CLK
2 DMIC_DATA
3 +3.3V
4 GND
Table 5-5: Audio DMIC-in Connector (DMIC1) Pinouts
PIN NO. DESCRIPTION
1 Battery +3.3V
2 GND
Table 5-6: Battery Connector (BT1) Pinouts
