AFL-W10A-N270 User Manual
Page 90
Table 5-16: RFID Connector (JP8) Pinouts
5.2.16 SATA Connector (SATA1)
5.2.17 Touch Panel Connector (TS1)
5.2.18 TTL Panel Connector (CN7)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 21 TFT_G5
PIN NO. DESCRIPTION
1 GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX+
7 GND
Table 5-17: SATA Connector (SATA1) Pinouts
PIN NO. 8-Wire 4-Wire 5-Wire
1 Right Sense N/A N/A
2 Left Sense N/A N/A
3 Bottom Sense N/A N/A
4 Top Sense N/A Sense (S)
5 Right Excite Right LR (X)
6 Left Excite Left LL (L)
7 Bottom Excite Bottom UR (Y)
8 Top Excite Top UL (Y)
9 GND GND GND
Table 5-18: Touch Panel Connector (TS1) Pinouts
