AFL-W10A-N270 User Manual
Page 89
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
13 REFCLK+ 14 N/C
15 GND 16 N/C
17 N/C 18 GND
19 N/C 20 N/C
21 GND 22 PERST#
23 PERn0 24 VCC3_AUX
25 PERp0 26 GND
27 GND 28 1.5 V
29 GND 30 SMBCLK
31 PETn0 32 SMBDATA
33 PETp0 34 GND
35 GND 36 USBD-
37 RESERVED 38 USBD+
39 RESERVED 40 GND
41 RESERVED 42 LED_WWAN#
43 RESERVED 44 LED_WLAN#
45 RESERVED 46 LED_WPAN#
47 RESERVED 48 1.5 V
49 RESERVED 50 GND
51 RESERVED 52 VCC3
Table 5-15: PCIe Mini Card Slot (CN2) Pinouts
5.2.15 RFID Connector (JP8)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 2 +5V
3 4 GND
5 6 RX2
7 8 TD2
9
For COM1 Pin 9
setting
10 RFID_INT
2 10
y y y y y
y y y y y
1 9
