AFL-W10A-N270 User Manual

Page 97

5.4.4 MCU LCD Type Selection Jumper (JP14)

Pin Description

Short 1-3

LCD Panel (Default)

Short 2-4

LED Panel

Table 5-35: MCU LCD Type Selection Jumper (JP14) Settings

5.4.5 MCU PWM Power Selection Jumper (JP13)

Pin Description

Short 1-2

+5V (Default)

Short 2-3

+3.3V

Table 5-36: MCU PWM Power Selection Jumper (JP13) Settings

5.4.6 Panel Type Selection Jumper (J_LCD_TYPE1)

Pin Description Pin Description

1 PA_DGPI0 2 GND

3 PA_DGPI1 4 GND

5 PA_DGPI2 6 GND

7 PA_DGPI3 8 GND

Table 5-37: Panel Type Selection Jumper (J_LCD_TYPE1) Settings

5.4.7 Touchscreen Selection Jumper (J1)

Pin Description

Short 1-2

5-wire (Default)

Short 3-4

4-wire

Table 5-38: Touchscreen Selection Jumper (J1) Settings
