5.3.5 SATA Connector (SATA2)
5.3.6 USB 2.0 Connectors (USB3)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +5Vsus 5 +5Vsus
2 D4F- 6 D5F-
3 D4F+ 7 D5F+
4 GND 8 GND
Table 5-30: USB 2.0 Connectors (USB3) Pinouts
5.4 Preconfigured Jumper Settings
The following jumpers are preconfigured for the AFL-W10A-N270. Users should not
change these jumpers (
77
Table 5-31 ). It is only for reference.
Jumper Name Label Type
Backlight voltage selection J_BL1 3-pin header
Inverter power selection JP12 6-pin header
LVDS voltage selection J_VLVDS1 3-pin header
PIN NO. DESCRIPTION
1 GND
2 STXP_0
3 STXN_0
4 GND
5 SRXN_0
6 SRXP_0
7 GND
7 GND
7 GND
Table 5-29: SATA Connector (SATA2) Pinouts
