SAILORPC-12A Panel PC

Page 79

Figure 6-2: DDR SO-DIMM Module Installation

6.5 Hard Drive and CompactFlash® Replacement

To replace the hard drive or CompactFlash® card, please refer to the hard drive and

CompactFlash® installation sections.

6.6 Cover Replacement

To ensure that the SAILORPC-12A remains water-tight, the instructions below must be

followed exactly.

Step 6:

Check the rubber seal is seated correctly.

WARNING:

The internal rubber seal must be correctly seated to stop water getting

into the system. Not installing the seal correctly can result in a short

circuit and destroy the system.
