SAILORPC-12A Panel PC

Page 24

3.6 Mounting the System

WARNING!

The panel PC is very heavy. Two or more people should mount the

panel PC. Dropping or bumping the panel PC during installation can

cause serious or irreparable damage to the panel PC.

The following installation options are available:

ƒ

Lift

stand

ƒ

Wall

arm

ƒ

Wall

mount

ƒ

Ceiling

mount

ƒ

Mobile

mount

The installation instructions are included with the stand, arm or mount.

3.7 Bottom Panel Connectors

The bottom panel connectors extend the capabilities of the panel PC but are not essential

for operation (except power).

Figure 3-11: Connectors
