SAILORPC-12A Panel PC

Page 14

3.1 Tighten the Pressure Release Screw

WARNING:

Fasten the pressure release screw on the back panel before use. The

pressure release screw is loosened before shipping, but must be

tightened before use to ensure the system is completely watertight.

Tighten the screw shown below to 7 kg-cm (6 lb-ft/0.68 Nm).

Figure 3–1: Pressure Release Screw
