SAILORPC-12A Panel PC

Page 46

Î

11 D

EFAULT

IRQ address 11

ƒ

Serial Port5 Address [2F0]

Selects the serial port base address.

Î

Disabled

No base address

Î

2F0 D

EFAULT

I/O address 2F0

ƒ

Serial Port5 IRQ [10]

Use the Serial Port5 IRQ option to select the interrupt address for serial port 5.

Î

10 D

EFAULT

IRQ address 10

5.3.4 Hardware Health Configuration

The Hardware Health Configuration menu (BIOS Menu 7) shows the operating

temperature, fan speeds and system voltages.

BIOS SETUP UTILITY

Main

Advanced

PCIPNP

Boot

Security

Chipset

Exit


Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU FAN Mode Setting

[Full On mode]

⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature

:68ºC/154ºF

System Temperature

:59ºC/138ºF


CPU Fan Speed

:N/A


CPU Core

:1.056 V

+1.05V :1.040

V

+3.30V :3.264

V

+5.00V :4.865

V

+12.0V :11.904

V

+1.50V :1.472

V

+1.80V :1.792

V

5VSB

4.919

V

VBAT

3.184

V














ÅÆ Select

Screen

↑ ↓ Select

Item

Enter Go to SubScreen
F1 General

Help

F10

Save and Exit

ESC Exit

v02.61 ©Copyright 1985-2006, American Megatrends, Inc.

BIOS Menu 7: Hardware Health Configuration
