Page 44: See table 3-14, Table 3-15
WAFER-945GSE2 3.5" Motherboard
Page 29
Pin Description Pin Description Pin Description Pin Description
A6
SD3
A22 SA9
B6
DRQ2
B22 IRQ6
A7
SD2
A23 SA8
B7
NC
B23 IRQ5
A8
SD1
A24 SA7
B8
-NOWS
B24 IRQ4
A9
SD0
A25 SA6
B9
+12V
B25 IRQ3
A10 IOCHRDY
A26 SA5
B10 GND
B26 -DACK2
A11 AEN
A27 SA4
B11 -SMEMW
B27 TC
A12 SA19
A28 SA3
B12 -SMEMR
B28 BALE
A13 SA18
A29 SA2
B13 -IOW
B29 VCC
A14 SA17
A30 SA1
B14 -IOR
B30 ISAOSC
A15 SA16
A31 SA0
B15 -DACK3
B31 GND
A16 SA15
A32 GND
B16 DRQ3
B32 GND
Table 3-14: PC/104 Connector Pinouts (1 of 2)
Pin Description Pin
Description Pin
Description Pin
Description
C1
GND
C11 -MEMW
D1
GND
D11 -DACK5
C2
-SBHE
C12 SD8
D2
-MEMCS16
D12 DRQ5
C3
SA23
C13 SD9
D3
-IOCS16
D13 -DACK6
C4
SA22
C14 SD10
D4
IRQ10
D14 DRQ6
C5
SA21
C15 SD11
D5
IRQ11
D15 -DACK7
C6
SA20
C16 SD12
D6
IRQ12
D16 DRQ7
C7
SA19
C17 SD13
D7
IRQ15
D17 VCC
C8
SA18
C18 SD14
D8
IRQ14
D18 -MASTER
C9
SA17
C19 SD15
D9
-DACK0
D19 GND
C10 -MEMR
C20 NC
D10 DRQ0
D20 GND
Table 3-15: PC/104 Connector Pinouts (2 of 2)
3.2.13 PC/104 Power Input Connector
CN Label:
CN1
CN Type:
3-pin wafer
CN Location:
CN Pinouts:
