PM-LX-800 CPU Card
4.3.8 Keyboard/Mouse Installation
The cable used to connect the motherboard to a keyboard or mouse is a 6-pin header to
PS/2 cable connector. To connect a keyboard or mouse to the motherboard, follow the
instructions below.
Step 1:
Step 2:
Step 3:
Step 1:
Step 2:
Step 3:
Step 1:
Find the KB/MS cable in the kit that came with the motherboard.
Connect the 6-pin connector end of the cable to the KBMS1 header on the
motherboard. A keyed pin on the connector prevents it from being connected
incorrectly.
Connect the other side of the cable to a keyboard and/or mouse using a
standard PS/2 connector.
Step 0:
4.3.9 LAN Installation
The cable used to connect the motherboard to a LAN is a 10-pin header to RJ-45
connector. To connect a LAN to the motherboard, follow the instructions below.
Find the LAN cable in the kit that came with the motherboard.
Connect the 10-pin connector end of the cable to the LAN1 box header on the
motherboard. A keyed pin on the connector prevents it from being connected
incorrectly.
Connect the other end of the cable to a standard RJ-45 connector.
Step 0:
4.3.10 LCD Backlight Installation
To connect an LCD backlight (inverter) to the motherboard, follow the instructions below.
Connect the 5-pin connector end of the LCD backlight cable to the CN5 header
on the motherboard. A keyed pin on the connector prevents it from being
connected incorrectly.
Step 0:
