PM-LX-800 CPU Card
The following components must be installed onto the motherboard or connected to the
motherboard during the installation process.
NOTE:
The PM-LX-800 motherboard has a preinstalled AMD CPU.
SO-DIMM module
Mount the motherboard onto a baseboard
4.3.1 DIMM Module Installation
4.3.1.1 Purchasing the Memory Module
When purchasing SO-DIMM modules, the following considerations should be taken into
account:
The maximum SO-DIMM capacity supported is 1GB
The maximum SO-DIMM frequency supported is 333 MHz.
The SO-DIMM chip must be a 200-pin memory chip
4.3.1.2 SO-DIMM Module Installation
The PM-LX-800 motherboard has one 200-pin SO-DIMM socket. To install the SO-DIMM
module, follow the instructions below.
Step 1:
Step 2:
Step 3:
Step 4:
Turn the PM-LX-800 over so that the SO-DIMM socket is facing up.
Push the SO-DIMM chip into the socket at an angle. (See Figure 4-1)
Gently pull the arms of the SO-DIMM socket out and push the rear of the
SO-DIMM module down. (See Figure 4-1)
Release the arms of the SO-DIMM socket. They clip into place and secure the
SO-DIMM module in the socket. Step 0:
