IEI® Technology, Corp.
Figure 3-8: IDE Interface Connector Location
3.2.7 Inverter Connector
CN Label:
CN5
CN Type:
5-pin header
CN Pinouts:
See Table 3-9
CN Location:
The Inverter connector connects to the LCD backlight.
