IEI® Technology, Corp.
1.2.1 PM-LX-800 Motherboard Connectors
The PM-LX-800 motherboard has the following connectors on-board:
1 x AT 12V/5V connector
1 x CFII compact flash connector (solder side)
1 x DDR SO-DIMM connector (solder side)
1 x IDE device connector
1 x Inverter connector
1 x Keyboard/Mouse connector
1 x LAN connector
1 x Parallel port connector
1 x PCI-104 connector
2 x RS-422 connectors
1 x RS-485 connector
1 x TTL/LCD connector
1 x USB connector
1 x VGA connector
The location of these connectors on the motherboard can be seen in Figure 1-1 and
Figure 1-2. These connectors are fully described in Chapter 3.
1.2.2 Technical Specifications:
PM-LX-800 motherboard technical specifications are listed in Table 1-1. Detailed
descriptions of each specification can be found in Chapter 2.
SPECIFICATION DESCRIPTION
CPUs Supported AMD™ Geode™ LX 800
Cache Memory 64K I/ 64k D L1 cache, 128K L2 cache
System Chipset AMD™ CS5536
I/O Controller AMD™ CS5536
Memory One 200-pin DDR 333MHz SO-DIMM SDRAM
with a maximum size of 1GB.
PCI Bus Interface Revision 2.2
Super IO W83627EHG
