PM-LX-800 CPU Card
Figure 3-16 RS-422/485 Serial Communications Connector Locations
3.2.15 TTL LCD Connector
CN Label:
CN4
CN Type:
40-pin headers (2x20 pins)
CN Pinouts:
CN Location:
TTL LCD (24-bit one channel; DF13-40DP-1.25V )
PIN
DESCRIPTION
PIN
DESCRIPTION
2 LCDVCC5
1 LCDVCC5
4 GND
3 GND
6 LCDVCC3
5 LCDVCC3
