Î
IO=2C8h;
IRQ=10, 11
IrDA I/O port address is 2C8h and the interrupt
address is IRQ10, 11
Î
IO=2D0h;
IRQ=10, 11
IrDA I/O port address is 2D0h and the interrupt
address is IRQ10 and IRQ11
Î
IO=2D8h;
IRQ=10, 11
IrDA I/O port address is 2D8h and the interrupt
address is IRQ10 and IRQ11
Î
IO=2E0h;
IRQ=10, 11
IrDA I/O port address is 2E0h and the interrupt
address is IRQ10 and IRQ11
5.3.6.3 Parallel Port Configuration
Use the Parallel Port Configuration menu (BIOS Menu 9) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=7
Change Settings
[Auto]
Device Mode [Printer Mode]
Change the Printer Port
mode
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 11: Parallel Port Configuration Menu
Î Parallel Port [Enabled]
Use the Parallel Port option to enable or disable the parallel port.
Î
Disabled Disable the parallel port
Î
Enabled D EFAULT Enable the parallel port
