NANO-PV-D4251/N4551/D5251 EPIC SBC
Page 54
4.6.2 Motherboard Installation
To install the NANO-PV-D4251/N4551/D5251 motherboard into the chassis please refer
to the reference material that came with the chassis.
4.7 Internal Peripheral Device Connections
This section outlines the installation of peripheral devices to the onboard connectors
4.7.1 AT/ATX Power Connection
Follow the instructions below to connect the NANO-PV-D4251/N4551/D5251 to an AT or
ATX power supply.
WARNING:
Disconnect the power supply power cord from its AC power source to
prevent a sudden power surge to the NANO-PV-D4251/N4551/D5251.
Step 1: Locate the power cable. The power cable is shown in the packing list in
Chapter 3.
Step 2: Connect the Power Cable to the Motherboard. Connect the 4-pin (2x2) Molex
type power cable connector to the AT/ATX power connector on the motherboard.
See Figure 4-12.
