NANO-PV-D4251/N4551/D5251 EPIC SBC
Page 7
Specification NANO-PV-D4251/N4551/D5251
Display Ports One VGA port (up to 2048x1536 for D4251/D5251, up to
1400x1050 for N4551)
One internal 18-bit single-channel LVDS connector (up to
1024 x 768 or 1366 x 768)
Ethernet Two RJ-45 GbE ports
Serial Ports One RS-232 serial port
Three RS-232 via four 10-pin headers
One RS-232/422/485 via 14–pin header
USB 2.0/1.1 Ports Two external USB ports
Six internal USB ports via three 8-pin headers
Parallel Ports One LPT connector via 26-pin header
Storage
Serial ATA Two SATA 3.0 Gb/s connectors with RAID 0,1 support
One 5 V SATA power connector
CompactFlash® One CompactFlash® Type II socket
Environmental and Power Specifications
Power Supply 12 V only
ATX and AT power supported
Power Connector One internal 4-pin Molex power connector for power supply
Power Consumption 12 V @ 2.21A (Intel® Atom™ D525 with 1GB 667Mhz DDR3)
Operating Temperature -20
°C~60°C without cooler, -20°C~70°C with forced air for
D525 processor
-20
°C~65°C without cooler, -20°C~70°C with forced air for
D425 processor
-20
°C~70°C without cooler, -20°C~75°C with forced air for
N455 processor
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
