NANO-9452 EPIC Motherboard
Page 47
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
29 GND 30 SMBCLK
31 PETN2 32 SMBDATA
33 PETP2 34 GND
35 GND 36 USBD-
37 N/C 38 USBD+
39 N/C 40 GND
41 N/C 42 N/C
43 N/C 44 RF_LINK#
45 N/C 46 BLUELED#
47 N/C 48 1.5V
49 N/C 50 GND
51 N/C 52 VCC3
Table 4-15: Mini PCIe Socket Pinouts
4.2.14 Parallel Port Connector
CN Label: LPT1
CN Type: 26-pin box header
CN Location: See Figure 4-16
CN Pinouts: See Table 4-16
The 26-pin parallel port connector connects to a parallel port connector interface or some
other parallel port device such as a printer.
