NANO-9452 EPIC Motherboard
Page 13
Family CPU Speed Processor # Bus Speed
Mfg
Tech
Cache
Size
1.86 GHz 440 533 MHz 65 nm 1 MB Celeron® M
1.73 GHz 530 533 MHz 65 nm 1 MB
Table 2-2: Supported Processors
2.5 Intel
®
945GME Northbridge Chipset
2.5.1 Intel
®
945GME Overview
The Intel® 945GME Northbridge chipset has the Generation 3.1 Intel® Integrated
Graphics Engine and the Intel® Graphics Media Accelerator 950 (Intel® GMA 950). The
integrated graphics and memory controller hub (GMCH) facilitates the flow of information
primarily between the following four interfaces:
 Front Side Bus (FSB)
 System Memory Interface
 Graphics Interface
 Direct Media Interface (DMI)
2.5.2 Intel
®
945GME Memory Support
WARNING:
Only DDR2 memory module can be installed on the NANO-9452. Do
not install DDR memory modules. If a DDR memory module is installed
on the NANO-9452, the NANO-9452 may be irreparably damaged.
The Intel® 945GME Northbridge chipset on the NANO-945GME supports one DDR2
200-pin SO-DIMM with the following features:
 One 200-pin SO-DIMM only
 DDR2 only (DO NOT install a DDR SO-DIMM)
 Single-channel or dual-channel
