NANO-9452 EPIC Motherboard
Page 146
The two scanning types can be selected interlaced (i) or progressive (p). Interlaced
scanning divides and presents each video frame as two fields. The first field presents the
odd lines and the second field presents the even lines. In progressive scanning, the image
is refreshed from top to bottom, one line after the other.
Configuration options are listed below:
Option Scan Type Vertical Lines Frame Frequency
Auto Auto Auto Auto
480i60 Interlaced 240 per field (480 per frame) 60 frames per second
480p60 Progressive 480 per frame 60 frames per second
576i50 Interlaced 283 per field (576 per frame) 50 frames per second
576p50 Progressive 576 per frame 50 frames per second
720p60 Progressive 720 per frame 60 frames per second
1080i50 Interlaced 540 per field (1080 per frame) 50 frames per second
1080i60 Interlaced 540 per field (1080 per frame) 60 frames per second
1080p24 Progressive 1080 per frame 24 frames per second
 TV Standard [Auto]
Use the TV Standard option to select the standard of the television connected to the
system. The configuration options are listed below.
 VBIOS-Default D EFAULT
 NTSC
 PAL
 SECAM
 SMPTE295M
 ITU-R television
 SMPTE295M
 SMPTE296M
 ETA-770.2
