ICE-CV-D25501/N26001 COM Express Module
Page 56
5.4 Chipset
Use the Chipset menu (BIOS Menu 16) to access the Host Bridge and Southbridge
configuration menus.
WARNING!
Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu
may cause the system to malfunction.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
> Host Bridge
> South Bridge
Host Bridge Parameters
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: Chipset
5.4.1 Host Bridge Configuration
Use the Host Bridge Configuration menu (BIOS Menu 17) to configure the Intel IGD
Configuration and display the memory information.
