ICE-CV-D25501/N26001 COM Express Module
Page 29
Step 5: Secure the SO-DIMM. Release the arms on the SO-DIMM socket. They clip into
place and secure the SO-DIMM in the socket.
4.4 Mounting the ICE-CV-D25501/N26001 to an Optional Baseboard
NOTE:
Baseboard can be designed by the end user, customized by IEI, or
purchased from IEI. For more information visit the IEI website
( www.ieiworld.com ) or contact an IEI sales representative.
WARNING:
Never run the COM Express module without the heat sink. The
heatspreader plate shipped with the ICE-CV-D25501/N26001 acts as a
thermal interface between the module and the heat sink. The heat sink
must be installed on the heatspreader plate to maintain proper
operating temperatures. Make sure to maintain the heatspreader plate
temperature under 60
°C in operation.
Follow the steps below to install the ICE-CV-D25501/N26001 to the optional baseboard.
Step 1: Align the two COM Express connectors on the reverse side of
ICE-CV-D25501/N26001 with the corresponding connectors on the baseboard.
Gently push the COM Express module down to ensure the connectors are
properly connected (Figure 4-2).
