ICE-CV-D25501/N26001 COM Express Module
Page 2
1.1 Introduction
Figure 1-1: ICE-CV-D25501/N26001
The ICE-CV-D25501/N26001 COM Express module provides the main processing chips
and is connected to a compatible COM Express baseboard. The ICE-CV-D25501/N26001
is equipped with an Intel® Atom™ D2550/N2600 CPU and Intel® NM10 PCH. The COM
Express standard allows the COM Express baseboard to be designed, while leaving the
choice of processor till the later stages of design. The ICE-CV-D25501/N26001 provides a
low power option with the full range of modern I/O options. The ICE-CV-D25501/N26001
embedded module is designed for flexible integration by system developers into
customized platform devices.
1.2 Model Variations
The model variations of the ICE-CV-D25501/N26001 are listed below.
Model No.
CPU
ICE-CV-D25501-R10
1.86 GHz Intel® Atom™ D2550
ICE-CV-N26001-R10
1.6 GHz Intel® Atom™ N2600
Table 1-1: ICE-CV-D25501/N26001 Model Variations
