ICE-CV-D25501/N26001 COM Express Module
Page 22
Pin No. Description Pin No. Description
C85 RSVD D85 RSVD
C86 RSVD D86 RSVD
C87 GND35 D87 GND31
C88 RSVD D88 RSVD
C89 RSVD D89 RSVD
C90 GND27 D90 GND24
C91 RSVD D91 RSVD
C92 RSVD D92 RSVD
C93 GND11 D93 GND32
C94 RSVD D94 RSVD
C95 RSVD D95 RSVD
C96 GND12 D96 GND33
C97 RSVD6 D97 RSVD
C98 RSVD D98 RSVD
C99 RSVD D99 RSVD
C100 GND13 D100 GND25
C101 RSVD D101 RSVD
C102 RSVD D102 RSVD
C103 GND D103 GND34
C104 VCC_12V1 D104 VCC_12V7
C105 VCC_12V2 D105 VCC_12V8
C106 VCC_12V3 D106 VCC_12V9
C107 VCC_12V4 D107 VCC_12V10
C108 VCC_12V5 D108 VCC_12V11
C109 VCC_12V6 D109 VCC_12V12
C110 GND14 D110 GND26
Table 3-3: COM Express Connector CD Pin Definitions
