ICE-CV-D25501/N26001 COM Express Module
Page 21
Pin No. Description Pin No. Description
C53 RSVD D53 RSVD
C54 RSVD D54 RSVD
C55 RSVD D55 RSVD
C56 RSVD D56 RSVD
C57 RSVD D57 TYPE2#
C58 RSVD D58 RSVD
C59 RSVD D59 RSVD
C60 GND7 D60 GND21
C61 RSVD D61 RSVD
C62 RSVD D62 RSVD
C63 RSVD1 D63 RSVD10
C64 RSVD2 D64 RSVD9
C65 RSVD D65 RSVD
C66 RSVD D66 RSVD
C67 RSVD3 D67 GND28
C68 RSVD D68 RSVD
C69 RSVD D69 RSVD
C70 GND9 D70 GND22
C71 RSVD D71 RSVD
C72 RSVD D72 RSVD
C73 DDI1_CTRLDATA D73 DDI1_CTRLCLK
C74 RSVD D74 RSVD
C75 RSVD D75 RSVD
C76 GND8 D76 GND29
C77 RSVD4 D77 RSVD
C78 RSVD D78 RSVD
C79 RSVD D79 RSVD
C80 GND10 D80 GND23
C81 RSVD D81 RSVD
C82 RSVD D82 RSVD
C83 RSVD5 D83 RSVD8
C84 GND6 D84 GND30
