ICE-CV-D25501/N26001 COM Express Module
Page 51
5.3.9.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 13) to configure fan
temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
SYS Smart Fan1 Mode [Manual Mode]
SYSFAN1 expect PWM Output/DC 255
Voltage Output
SYS Smart Fan2 Mode
[Manual Mode]
SYSFAN2 expect PWM Output/DC 255
Voltage Output
SYS Smart Fan1 Mode
Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: Smart Fan Mode Configuration
SYS Smart Fan1/Fan2 Mode [Manual Mode]
Use the Sys Smart Fan1/Fan2 Mode option to configure the system smart fans.
Manual Mode D EFAULT The fan spins at the speed set in
SYSFAN1/SYSFAN2 expect PWM Output/DC
Voltage Output settings.
Thermal
Cruise Mode
The fan adjusts its speed using
SYSFAN1/SYSFAN2 Target Temperature and
SYSFAN1/SYSFAN2 Tolerance of Target
Temperature settings.
Fan Speed
Cruise Mode
The fan adjusts its speed using
SYSFAN1/SYSFAN2 Target Speed Count and
SYSFAN1/SYSFAN2 Tolerance of Target Speed
Count settings.
