ICE-CV-D25501/N26001 COM Express Module
Page 18
Pin No.
Description
Pin No.
Description
A97
RSVD
B97
RSVD
A98
RS1_TX
B98
RSVD
A99
RS1_RX
B99
RSVD
A100
GND13
B100
GND25
A101
RS2_TX
B101
FAN_PWMOUT
A102
RS2_RX
B102
FAN_TACHIN
A103
LID#
B103
SLEEP#
A104
VCC_12V7
B104
VCC_12V16
A105
VCC_12V8
B105
VCC_12V17
A106
VCC_12V9
B106
VCC_12V18
A107
VCC_12V10
B107
VCC_12V19
A108
VCC_12V11
B108
VCC_12V20
A109
VCC_12V12
B109
VCC_12V21
A110
GND14
B110
GND26
Table 3-2: COM Express Connector AB Pin Definitions
3.2.2 COM Express Connector CD
CN Label:
J2
CN Type:
220-pin COM Express connector
CN Location:
CN Pinouts:
The standard COM Express connector CD location and pinouts are shown below.
