Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+39 C
SYS Temperature
:+40 C
CPU FAN Speed
:4950 RPM
VCC3V
:+3.312 V
V_core :+1.168
V
Vcc
:+2.606
V
Vcc12
:+11.792 V
V1_5VDDR :+1.504
V
VSB3V
:+3.408 V
VBAT
:+3.264
V
CPU Smart Fan control
[Auto Mode]
Temperature Bound1
60
Temperature Bound2
50
Temperature Bound3
40
Temperature Bound4
30
: Select Screen
: Select Item
Enter
Select
F1 General
Help
F2 Previous
Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 12: Hardware Health Configuration
PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
System
Temperatures:
o
CPU Temperature
o
System Temperature
Fan
Speeds:
o
CPU Fan Speed
Voltages:
o
V_core
o
Vcc
o
Vcc12
o
V1_5VDDR
o
VSB3V
o
VBAT
