PCISA -9652 Half-Size CPU Card

Page 61

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1 STROBE#

2 DATA

0

3 DATA

1

4 DATA

2

5 DATA

3

6 DATA

4

7 DATA

5

8 DATA

6

9 DATA

7

10

ACKNOWLEDGE

11 BUSY

12 PAPER

EMPTY

13 PRINTER

SELECT 14 AUTO

FORM

FEED

#

15 ERROR#

16 INITIALIZE

17 PRINTER

SELECT

LN#

18 GROUND

19 GROUND

20 GROUND

21 GROUND

22 GROUND

23 GROUND

24 GROUND

25 GROUND

26 NC

Table 4-17: Parallel Port Connector Pinouts

4.2.16 SATA Drive Connectors

CN Label:

S_ATA1, S_ATA2 and S_ATA3

CN Type:

7-pin SATA drive connectors (1x7)

CN Location:

See Figure 4-18

CN Pinouts:

See Table 4-18

The three SATA drive connectors are connected to three SATA II drives. SATA II drives

transfer data at speeds as high as 3.0Gbps.
