M S ERIES CCT C ONFIGURATION G UIDE
22
every 5, 10, 15, 30, or 60 minutes. All data samples are printed on the strip chart regardless of
this setting.
Trending Enabled
When set to “Yes”, the M Series CCT unit will print and display trend reports as long as the
appropriate hardware is installed. Defaults to “No” for units not equipped with the appropriate
hardware.
AED Defib Ready Hold Time (AED Semi-Automatic
Mode)
Sets the number of seconds the unit sounds a charge ready tone, indicating that the defibrillator
is charged and ready to use. The charge ready tone stops when you discharge the defibrillator or
when the hold time for the charge ready tone has elapsed. You can set the hold time for the
charge ready tone to 15 seconds or 60 seconds. The default is 15 seconds.
Battery Type Used
Allows the user to select between the PD™ 4410 battery (default) and the newer XL™ battery.
To maximize battery life, it is important that the setting reflect the actual battery in use. Each
battery type has a different threshold for “low battery” and “shutdown”, and has a different
Amp-hour rating.
WARNINGS:
If an XL battery is installed in an M Series CCT, the user must ensure that the “BATTERY
TYPE USED” is set to “XL Battery.” Otherwise, the M Series CCT may abnormally
terminate battery charging prior to completion when charging a depleted or nearly depleted
XL battery. If battery charging is abnormally terminated, the M Series CCT battery will
toggle the “CHARGER ON” light between amber and green, and, when M Series CCT
power is applied, it will display the message “BATT. OVERCHARGE” on the screen for
approximately 30 seconds.
Note that if battery charging is abnormally terminated because the “BATTERY TYPE
USED” has been incorrectly set to “PD 4410”, the XL battery can still be charged to
completion by cycling M Series CCT power from “off” to “on” and then back to “off” to
clear this condition.
Incorrectly setting “BATTERY TYPE USED” to “PD 4410” when an XL battery is installed
will cause the “LOW BATTERY” warning message to be displayed on the M Series CCT
screen prematurely.
Incorrectly setting the selection to “XL battery” when a PD 4410 battery is installed will
inappropriately delay issuance of the “LOW BATTERY” warning and severely limit the
number of defibrillation shocks which can be delivered between the onset of the “LOW
BATTERY” warning message and the M Series CCT shutdown.
