Operation, Operating controls and indicators – ZOLL AED Plus Rev V User Manual
Page 13
ZOLL AED PLUS Administrator’s Guide
3
Operation
This section describes the following functions:
• Operating Controls and Indicators
• Using the AED Plus Graphical User Interface
• Voice Prompts
• Using the LCD Display
• Using the Passive Airway Support System (PASS)
• Using Electrodes
• Applying CPR-D
-
padz
• Applying pedi
-
padz II
®
(Infant/Child Electrodes)
• Using the CPR Monitoring Function — Real CPR Help
• Using the Audio Recording Option
Operating Controls and Indicators
See Table 1: Control Functions for an explanation of each of these controls.
Figure 1: Identifying Operating Controls and Indicators
LCD Display (not supplied on
some units)
Graphics
Indicator Lights
Electrode Connector
Status
Indicator
Carrying Handle
On/Off Button
IrDA Port (on side of unit)
Battery Compartment (bottom)
Microphone (hidden)
Shock Button
Speaker (bottom)
