Specification Overview
Mechanical Features:
Note: Special function and combinations of foot
switches can be designed and
manufactured to meet the customer’s own
design performance and
requirements. For information consult
the Sales Office at 1-800-451-8279.
Ordering Example:
The following order has to be observed.
1. The type of desired device by number of
pedals.
Example:
F1, F2, F3
2. The number and type of contact block. For
switches with several pedals indicate from left to
right.
Example: F3-
U1/U1Y/U2D UN
3. The indications concerning additional functions,
versions or pedals have to be given in the
description, directly behind the
corresponding switching element.
Example with detent detent and pressure point:
F3-U1/U1
Y/U2D UN
4. Indciations on special equipment which does not
depend on the pedal have to be given at the end
of the type designation.
Example: F2-U1/U1
AP
5. Versions with proection shield are marked at the
end of the type designation by UN. Example: F2-
U1/U1 AP
UN
Case Material Aluminum die cast
Protective Guard Aluminum die cast
Actuator Foot Lever
Ambient Air
Temperature
-22ºF to 176ºF
Switch Action Dependent upon switch selected
Contacts Dependent upon switch selected
Mechanical Life 10 x 10 6 Switch Operations
Switching
Frequency
50 times per minute
Mounting Free standing on rubber bumpers
Terminals 4 screw terminals per contact block
Cable Entries
All switches supplied with a 1/2 inch
Conduit Adapter
Weight
Approximate:
Without Guards
F1
≈1.5 lbs. (.7 kg)
F2 ≈3.7 lbs. (1.7 kg)
F3 ≈6.8 lbs. (3.1 kg)
With Guards
F1
≈3.3 lbs. (1.0 kg)
F2 ≈5.7 lbs. (2.6 kg)
F3 ≈11.9 lbs. (5.9 kg)
Electrical Features:
Maximum Voltage 500 VAC
Enduring Current 20 AMPS
Inrush Current Per IEC 947-5-1, AC 15, DC 13
Standards
According to VDE 0660, 0113,
IEC 947-5-1
Protection Class
NEMA 4, IP65 According to
DIN 40 050
UL / CSA Approved
10 AMP, 300 VAC, A300
(Same Polarity)
