Page 6
6
Warner Electric • 800-825-9050
819-0343
Figure 9
If the armature for either the clutch or the
brake is too far away from its mating friction
surface, it is possible to move this back into
adjustment using a flat head screwdriver.
This is a three-step process.
1. Simply slide the screwdriver through the
window and press the armature toward its
mating friction surface.
2. Rotate the output of the unit. The rotor
and window should stay in place when you
do this. Only the armatures will move.
Rotating the rotor will move the window.
3. Repeat steps 1 & 2 to ensure that the air-
gap between the armature and its mating
friction surface is about 1/32" and that the
armature is kept square. (If the armature is
cocked, it may engage on one rim, giving
the appearance of engagement but failing
to provide full torque.)
If a scraping sound is noted when the output
shaft is spun, it means an armature is drag-
ging. Insert a screwdriver through the vent
holes and slot in the fan and pry the dragging
armature (clutch or brake as observed) away
from the mating surface evenly all the way
around. Re-check the engagement as
described in step B of the Start-Up instruc-
tions.
Electrical Coil Data
Clutch Brake Clutch Brake Clutch Brake
Voltage–D.C.
90
90
24
24
6
6
Resistance
UM-50
452
452
31.8
31.8
1.86
1.86
(OHMS)
UM-100/180
392
392
26.7
26.7
1.81
1.81
UM-210/215
248
248
17.9
17.9
1.22
1.22
Amperes
UM-50
.199
.201
.755
.755
3.23
3.23
UM-100/180
.230
.230
.896
.896
3.31
3.31
UM-210/215
.363
.363
1.34
1.34
4.9
4.9
WATTS (17.9) UM-50
18
18
18.1
18.1
19.4
19.4
UM-100/180
20.7
20.7
21.5
21.5
20.0
20.0
UM-210/215
32.7
32.7
32
32
29.6
29.6
Build Up
UM-50
52
53
52
53
52
53
(Milliseconds) UM-100/180
72
75
72
75
72
70
UM-210/215
120
100
120
100
110
100
Decay
UM-50
6.2
5.0
6.2
5.0
6.5
5.0
(Milliseconds) UM-100/180
12
10
12
10
12
10
UM-210/215
20
10
20
10
20
10
Mechanical Data
UM-50
UM-100/180
UM-210/215
Static Torque - lb. ft.
16
30
95
Maximum Speed - rpm
3600
3600
3600
Average Weight-lbs.
1020
10
13.2
30.6/31
1040
8.3
10.3
24.3/25
2030
13
16.5
41.3/42
3040
11.3
13.6
35/35.5
Inertia - WR - lb.ft.
Configuration
50
100/180
210
215
1020 input
.021
.047
.190
.190
1020 output
.0195
.050
.193
.195
1040 input
.021
.047
.190
.190
1040 output
.0105
.027
.112
.114
2030 input
.021
.048
.198
.200
2030 output
.0195
.050
.193
.195
3040 input
.021
.048
.198
.200
3040 output
.0105
.027
.112
.114
