4.7 Working with Dynamic Test Results (LTCA Only)
When a test record from a dynamic test has been retrieved (see sections 4.1 and 4.2 for
instructions), the graphic results will be displayed as shown below:
As with static resistance test results, you can click on the Edit icon in the ribbon to edit the
header information.
Dynamic Resistance Graph
Motor Current Graph
Main Current Graph
