REV 3 LTCA VERSION 2.xx SOFTWARE MANUAL

To export the test record, simply save the test record by either clicking on the Save icon,
or by selecting Save from the File menu.

Test records are stored in the “Tests” folder in the LTCA software’s installation directory.
If using default installation settings, the folder will be located at
“C:\Vanguard\LTCA\Tests”. Files exported in Excel, PDF, and XML formats are stored in
subfolders named respectively under the “Tests” folder. For example, Excel files will be
stored at “C:\Vanguard\LTCA\Tests\Excel”.

NOTES

• When a test record is automatically exported to PDF, the PDF file will

not contain the graph. If you would like to include the graph in the PDF
file, please use the manual Export option (please see the following
section).

• When a test record is automatically exported in Excel format, the graph

will be embedded in the Excel file. However, the graph will be a full-
scale graph displaying all data points. If you prefer to export an
expansion graph, please use the manual Export option (please see the
following section).

• When a test record is automatically exported in XML format, two files

are created. The XML data will be exported to a file with the “.xml”
extension while the graph will be exported to a file with the “.bmp”
extension. The graph will be a full-scale graph displaying all data points.
If you prefer to export an expansion graph, please use the manual
Export option (please see the following section).
