REV 2 CT-8000 USER’S MANUAL

3.7.3. Printing a Breaker Test Plan

Follow the steps below to print a breaker test plan stored in the CT-8000’s Flash EEPROM:

a. Start from the “START-UP” menu:

Press the

[3]

key (SETUP).

b. The following screen will be displayed:

Press the

[1]

key (ANALYSIS POINTS).

c. The following screen will be displayed:

Press the

[4]

key (TEST PLANS).

d. The following screen will be displayed:

Press the

[2]

key (PRINT TEST PLAN).

e. The first test plan stored in the CT-8000’s Flash EEPROM will be listed:

You can scroll through the list of test plans by pressing the

[PAPER ∧ Contrast]

and

[PAPER ∨ Contrast]

keys. Once you have located the test plan that you would like to

print, press the

[ENTER]

key. The test plan will be printed on the built-in thermal

printer and you will be returned to the “START-UP” menu. A sample breaker test plan
printout is shown in Figure 37.

TEST PLAN # 01

BZO-145-20-7
SIEMENS
DEMO TEST PLAN 1

1. LOAD TEST PLAN

2. PRINT TEST PLAN

3. PRINT DIRECTORY

1. OPEN TIMING

2. CLOSE TIMING

3. PRINT SETTINGS

4. TEST PLANS

1. ANALYSIS POINTS

2. MEASUREMENT UNITS

3. SAVE / RESTORE

4. NEXT PAGE

1. RUN TEST 03/10/10

2. GET RSLT 09:04:05

3. SETUP

4. DIAGNOSTICS
