3.2.7. Configuring the Channel Settings
The CT-8000 is available with 3 or 6 contact inputs. Since most common timing applications
require the use of only 3 contact timing channels and one travel transducer channel, there is no
need to print data for more than 3 timing channels and one transducer channel on the graphic
and tabulated reports. The CT-8000’s is configured to print 3 contact channels by default
(channels 1, 2, and 3) and one transducer channel (transducer channel #1). The default settings
can be changed using the steps below:
a. Start from the “START-UP” menu:
Press the
[3]
key (SETUP).
b. The following screen will be displayed:
Press the
[4]
key (NEXT PAGE).
c. The following screen will be displayed:
Press the
[2]
key (NUMBER OF CHANNELS).
d. The following screen will be displayed:
Press either the
[1]
key (3 CONTACTS) or the
[2]
key (6 CONTACTS) to select the
corresponding number of contact channels.
NUMBER OF CHANNELS
1. 3 CONTACTS
2. 6 CONTACTS
1. SHOT DESCRIPTION
2. NUMBER OF CHANNELS
3. SET DATE & TIME
4. NEXT PAGE
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
1. RUN TEST 03/10/10
2. GET RSLT 09:04:05
3. SETUP
4. DIAGNOSTICS
