REV 2 CT-8000 USER’S MANUAL
72
3.4 Performing a Static Resistance Test
The CT-8000 can also be used as a 200 Ampere micro-ohmmeter. A typical connection for this
application is shown in Figure 11. Follow the steps below to perform a static resistance test:
a. Start from the “START-UP” menu:
Press the
[1]
key (RUN TEST).
b. The following screen will be displayed:
Press the [2] key (STATIC RES TEST).
c. The following screen will be displayed:
Press the [ENTER] key.
d. The following screen will be displayed momentarily:
Once the test is complete, the results will be displayed as shown below:
Press any key to return to the “START-UP” menu. You can print the test results using the
instructions in section 3.3.5. A typical static resistance report is shown in Figure 30.
TEST COMPLETE
RES = 291.6 u-Ohms
CUR = 205.9 A
CABLES ENERGIZED!
STATIC RES TEST
CONNECT DCR CABLES
THEN
“ENTER” TO BEGIN
1. TIME BREAKER
2. STATIC RES TEST
3. DYNAMIC RES TEST
1. RUN TEST 03/10/10
2. GET RSLT 09:04:05
3. SETUP
4. DIAGNOSTICS
