CT-8000 USER’S MANUAL
REV 2
35
3.2.8. Configuring the Contact Filter Settings
Although the CT-8000 automatically detects the contact time using its own algorithm, it also
allows the user to enter a custom filter value. The value can be between 1 and 300. A filter
setting of 1 allows the CT-8000 to pick up the first contact transition time after the resistor
contact activity is detected. A filter setting of 300 allows the CT-8000 to pick up the last contact
transition time after the resistor contact activity is detected. Use the steps below to set the
contact filter value:
a. Start from the “START-UP” menu:
Press the
[4]
key (DIAGNOSTICS).
b. The following screen will be displayed:
Press the
[4]
key (NEXT PAGE).
c. The following screen will be displayed:
Press the
[3]
key (CONTACT FILTER).
d. The following screen will be displayed:
Type the new filter value using the numeric keypad and then press the
[ENTER]
key.
The contact filter value will be set and you will be returned to the “START-UP” menu.
NOTE
The filter value will be reset to the automatic setting when the unit’s power is
cycled.
ENTER FILTER SETTING
(1 – 300)
CURRENT SETTING: 1
NEW SETTING?
1. PRINT DATA
2. ENCODER FILTER
3. CONTACT FILTER
1. SLOW CLOSE TEST
2. CHECK HOOKUP
3. TEST TRANSDUCER
4. NEXT PAGE
1. RUN TEST 03/10/10
2. GET RSLT 09:04:05
3. SETUP
4. DIAGNOSTICS
