3.2.11. Configuring the Resister Type Transducer Settings

The CT-8000 provides one channel for a resistor type transducer. The transducer must be
configured before it can be used with the CT-8000. Up to 9 resistor transducer setups can be
stored in the CT-8000’s Flash EEPROM. When a resistive transducer is used with the CT-8000, it
is shown as transducer #1 on the timing report as shown in Figure 17.

Creating a New Resistor Type Transducer Setup

Follow the steps below to create a new resistor type transducer setup:

a. Start from the “START-UP” menu:

Press the

[3]

key (SETUP).

b. The following screen will be displayed:

Press the

[2]

key (MEASUREMENT UNITS).

c. The following screen will be displayed:

Press the

[4]

key (RES ENC).

d. The following screen will be displayed:

Press the

[1]

key (CREATE NEW SETUP).

RESISTIVE ENCODER
1. CREATE NEW SETUP

2. LOAD SETUP

3. PRINT SETUP DIR

SELECT UNITS:
1. ENGLISH

2. METRIC

3. ROT ENC 4.RES ENC

1. ANALYSIS POINTS

2. MEASUREMENT UNITS

3. SAVE / RESTORE

4. NEXT PAGE

1. RUN TEST 03/10/10

2. GET RSLT 09:04:05

3. SETUP

4. DIAGNOSTICS
