CT-6500 Operating Instructions
49
9.16 Check Cable Hookup
Table 21.0 Checking the Cable Hookup
STEP OPERATION ACTION DISPLAY
1 SELECT DIAGNOSTIC. PRESS # 4 KEY. 1. SLOW-CLOSE TEST
2. PRINT DATA
3. TEST TRANSDUCER
4. CHECK HOOKUP
2 SELECT CHECK HOOK UP. PRESS # 4 KEY. MAKE SURE BREAKER
IS IN CLOSE POSITION,
THEN PRESS "START"
3 INITIATE TEST. PRESS THE "START"
KEY.
1 2 3
C - - -
4 RETURN TO MAIN MENU. PRESS THE "STOP"
KEY.
1. TIME BREAKER
2. GET RESULT
3. SET UP
4. DIAGNOSTIC
NOTES
1. The CT-6500 will also print the test report with the thermal printer.
2. A contact closure is shown as "C" on the LCD and printout.
3. An open contact is shown as "-" on the LCD and printout.
