CT-6500 Operating Instructions
33
9.5 Printing Timing Shot Directory Stored in the EEPROM
The user can obtain a timing-shot directory that was stored in the CT-6500’s FLASH
EEPROM by using the following steps in Table 11.0.
Table 11.0 Print Timing Shot Directory
STEP OPERATION ACTION DISPLAY
1 SELECT SETUP MENU. PRESS #3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT SAVE/RESTORE MENU. PRESS #3 KEY. 1. SAVE SHOT
2. RESTORE SHOT
3. SHOT DIRECTORY
4. ERASE SHOT
3 SELECT SHORT DIRECTORY. PRESS # 3 KEY. 1. SHORT DIRECTORY
2. FULL DIRECTORY
"STOP" TO QUIT
4 SELECT SHORT DIRECTORY. PRESS #1 KEY. PRINTING ABBREVIATED
DIRECTORY
“STOP” TO QUIT
5 RETURN TO MAIN MENU. NO ACTION. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
NOTE
1. If the "Short Directory" was selected, the CT-6500 will print out the shot
identifications of the last ten timing shots stored in the EEPROM.
2. If the "Full Directory" was selected, the CT-6500 will print out the shot
identifications of all the timing shots stored in the EEPROM.
3. A typical shot directory printout is shown on next page, in Figure 16.0.
