CT-6500 Operating Instructions
35
9.6 Recalling a Timing Shot
The following steps in Table 12.0 are used to recall a timing shot stored in the EEPROM to the
working memory. Once a timing shot is recalled, the user can ask for a printout of the test results
from the thermal printer.
Table 12.0 Recalling a Timing Shot
STEP OPERATION ACTION DISPLAY
1 SELECT SETUP MENU. PRESS #3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT SAVE/RESTORE SHOT. PRESS # 3 KEY. 1. SAVE SHOT
2. RESTORE SHOT
3. SHOT DIRECTORY
4. ERASE SHOT
3 SELECT RESTORE SHOT. PRESS #2 KEY. ENTER SHOT NUMBER
TO BE RESTORED
XXXX
"ENTER" TO CONFIRM
4 ENTER SHOT NUMBER “1” TO BE
RESTORED.
PRESS KEYS 0-9
FOR SHOT ID THEN
PRESS THE "ENTER"
KEY.
ENTER SHOT NUMBER
TO BE RESTORED
0001
"ENTER" TO CONFIRM
5 CONFIRM SHOT TO BE RESTORED. PRESS THE "ENTER"
KEY.
RESTORING SHOT # 0001
TEST: OPEN
DATE: 03\12\03 09:12
"ENTER" TO CONFIRM
6 CONFIRM TEST RESTORED. NONE. RESTORE COMPLETE
7 RETURN TO MAIN MENU. PRESS ANY KEY. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTICS
