Vanguard Auto-Ohm 100_200 s2 User Manual
Page 3
AUTO-OHM 100/200 Series 2 Operating Procedures
3
Rev 3, 2009
Table of Contents
1.0 INTRODUCTION .............................................................................................................. 6
1.1 Applicability ......................................................................................................................... 6
1.2 General Description .............................................................................................................. 6
1.3 Functional Description.......................................................................................................... 6
1.4 Furnished Test Accessories................................................................................................... 6
1.5 Optional Accessories ............................................................................................................ 9
2.0 AUTO-OHM
SPECIFICATIONS .................................................................................... 10
2.1 Auto-Ohm 100 Series 2 Specifications............................................................................... 10
2.2 Auto-Ohm 200 Series 2 Specifications............................................................................... 11
3.0
CONTROL AND DISPLAY ............................................................................................ 12
3.1 Auto-Ohm 100 Series 2 Front Panel................................................................................... 12
3.2 Auto-Ohm 200 Series 2 Front Panel................................................................................... 14
4.0 OPERATING
VOLTAGES.............................................................................................. 16
5.0 CABLE
CONNECTION .................................................................................................. 16
6.0 OPERATING
THE
AUTO-OHM .................................................................................... 19
6.1 Step-by-Step Procedures..................................................................................................... 19
6.2 Precautions.......................................................................................................................... 19
6.3 Preparations......................................................................................................................... 19
6.4 Running a Normal Test Procedure...................................................................................... 20
6.5 Running an Automatic Test Procedure ............................................................................... 23
6.6 Auto-Ohm Quick Test Procedure ....................................................................................... 25
6.7 Contrast Adjustment ........................................................................................................... 25
6.8 Auto-Ohm Calibration Check ............................................................................................. 26
6.9 Display Previous Results .................................................................................................... 29
List of Tables
Table 1.0
Auto-Ohm 100 Series 2 Specifications............................................................. 10
Table 2.0
Auto-Ohm 200 Series 2 Specifications............................................................. 11
Table 3.0
Functional Description of Auto-Ohm 100 Series 2 Controls and Display ....... 13
Table 4.0
Functional Description of Auto-Ohm 200 Series 2 Controls and Display ....... 15
