AUTO-OHM 100/200 Series 2 Operating Procedures
28
Rev 3, 2009
the display. The Auto-Ohm will continue to beep until the control knob is pressed. Once the
problem has been fixed, the CAL CHECK can be rerun.
Figure 44.0 Zero Circuit Test Message
f. The Auto-Ohm checks the ZERO circuit. The “PASS” message is displayed as shown above
in Figure 44.0.
Figure 45.0 Full-Scale Circuit Test Message
g. The full scale range check (FSCL CKT CHECK) is performed next. The “PASS” message is
displayed as shown above in Figure 45.0.
h. The measure circuit test (MEASURE CKT CHECK) is performed next. The “PASS”
message displays as shown below in Figure 46.0.
Figure 46.0 Measure Circuit Test Message
i. If all of the calibration functions pass, the Auto-Ohm calibration complete message appears as
shown in Figure 47.0.
Figure 47.0 Cal Check Complete Message
This completes the Calibration Check procedure. Press the control knob to return to the MAIN
MENU.
MEASURE CKT CHECK
“PASS”
CAL CHECK DONE!
PRESS KEY……....
ZERO CKT CHECK
“PASS”
FSCL CKT CHECK
“PASS”
