AUTO-OHM 100/200 Series 2 Operating Procedures
25
Rev 3, 2009
Figure 33.0 Automatic Mode Test results
g. To initiate another test, disconnect and reconnect the sense leads to the device under test. To
terminate the Automatic Test Mode, press the Auto-Ohm control knob.
NOTE
The user should allow two seconds between disconnecting and reconnecting to the test
leads to initiate a new test.
6.6 Auto-Ohm Quick Test Procedure
The Auto-Ohm Quick Test mode is a preset test that runs a test at 100 Amps for 5 seconds. To
start a quick test, go to the RUN TEST option in the MAIN MENU. Press and hold the control
knob for 2 seconds. A short beep will be heard at which point the knob must be quickly released.
The Auto-Ohm will beep twice to acknowledge the quick test command has been accepted. Press
then release the control knob again to initiate the test. The Auto-Ohm will run a 100A test with a
5-second burn in time (Figure 34.0). The displayed test result will resemble Figure 33.0.
Figure 34.0 Quick Test Menu
6.7 Contrast Adjustment
The purpose of this procedure is to adjust the darkness level of the alpha-numeric characters
shown in the LCD display, in order to produce the best readability for the ambient light in the
testing area. To adjust the contrast, turn the control knob to select the ADJ. CONTRAST option
from the MAIN MENU as shown in Figure 35.0.
Figure 35.0 Select Adjust Contrast Menu
a. Press the control knob to select ADJ. CONTRAST mode. The following menu (Figure 36.0)
will be shown.
Figure 36.0 Contrast Menu
MAIN MENU
ADJUST CONTRAST
“PRESS”= DONE
I=10 AMPS
101.0 MICRO-OHM
100 AMPS 5 SEC
“PRESS” TO RUN
