AUTO-OHM 100/200 Series 2 Operating Procedures

Rev 3, 2009

6.9 Display Previous Results
The purpose of this procedure is to let an operator view the last 3 readings stored in the Auto-
Ohm. To view previous results, turn the control knob to select the PREV RESULTS option
from the MAIN MENU, as shown in Figure 48.0.

Figure 48.0 Previous Results Menu

a. Press the control knob to select this option. The user now can select any of the last three
readings to be displayed. To select the reading, turn the control knob to one of the menus.

Figure 49.0 Select Reading Menus

b. When one of the prompts above displays, press the control knob to display its reading. The
test results will be displayed as shown in Figure 50.0 below.

Figure 50.0 Test Record Readout

c. The above display shows the recorded test resistance (120.2 Micro-ohms) and the test current
level (100 amps) at which it was measured. When the displayed record of resistance is reviewed
and noted, press the control knob to return to the MAIN MENU. This ends the PREVIOUS
RESULTS procedure.

NOTE

To display previous test results, the Auto-Ohm must contain tests performed since it was last
(most recently) powered on. When the Auto-Ohm is powered off, it loses all test information.

This concludes the operating procedures for all of the Auto-Ohm functions.

PREVIOUS RESULTS

I= 100AMPS

120.2 MICRO-OHM

PREVIOUS RESULTS

MAIN MENU
