Bluetooth Adapt Spvr Prt Installation Instructions TG200977 Issue 1/B 25/06/07

7

Installation Instructions

BLUETOOTH ADAPT SPVR PRT

a

The browser now appears with a tick alongside
the Bluetooth icon

b

Double-click the Bluetooth icon. The browser
will now display a single icon titled ‘Bluetooth
Serial Port on TREND Bluetooth xxxx’.

c

Double click the icon and a dialog similar to
that shown will appear. Note the port number.

Determine Serial Port Number

4

5.2 On Windows 2000

(continued)

Configure Serial Port and Baud Rate

5

a

Start the Trend software as normal.

b

Set system connection to serial port, with a
9600 baud rate, and the serial port number
shown in step 4

Note that SET and other TCC based applications
are not currently capable of using ports greater
than COM15. If your PC Bluetooth adapter selects
a port number greater than this it cannot be used.
Refer to the adapter documentation of the supplier
to determine how to make it select a port number
in the useable range.

6 Disposal

WEEE Directive :

At the end of their useful life the packaging
and product should be disposed of by a
suitable recycling centre.

Do not dispose of with normal household waste.
Do not burn.
