TREND HT_S User Manual
Ht/s space humidity and temperature sensor, Installation instructions
HT/S Space Humidity and Temperature Sensor Installation Instructions TG200990 Issue 1/A 30/01/08
1
Installation Instructions
HT/S
Space Humidity and Temperature Sensor
Important: Retain these instructions
2 Installation
1 Unpacking
HT/S Installation
Instructions
TG200990
Dimensions
1
86 mm (3.39”)
26 mm (1.02”)
86 mm (3.39”)
Requirements
2
b
a
c
> 50 cm (20”)
e
d
f
g
1.5 m
(5 ft)
Contents
1
Unpacking .................................................... 1
2
Installation .................................................... 1
3
Maintenance ................................................. 4
4
Disposal ....................................................... 4
